Guitar Data Sheet

Serial Number:       20-10

Date:  June 16, 2021

Guitar Style   OM/CW/ 14 Fret

Top Wood:  Engelman Spruce

Body Wood:  Figured Walnut

Nut Material:  Bone

Saddle Material/Comp:  Tusq Compensated

Bridge Material:  Ebony

End Graft:  Book matched Sycamore

Tuning Machines:  Grover # 305 Medium Chrome

Neck Shape:  Modified V (Martin)

Bridge String Spacing:  2.375 inches

Neck Binding: Walnut with green veneer purfling.

Body Binding:  Walnut/Maple on top; Maple on bottom. Green purfling

Headstock Binding:  None; Walnut and Sycamore Veneers

Inlay Materials and Styling:  MOP logo and fingerboard dots; black dots on side

Bracing Material: Red Spruce

Top Bracing Width:  .25 inches

Scallop Height:  .625 inches

Back Bracing Pattern:  Ladder

Finish Details:  Epoxy fill; 6 coats lacquer, polish

Strings: D’Addario Light

Monopole Mobility: 17.3

Final Frequencies: 104, 180
