Guitar Data Sheet

Serial Number:       20-14

Date:  7/7/2021

Guitar Style   OOO-12 Cut Away

Top Wood:  European Spruce

Body Wood:  Figured Walnut

Nut Material:  Bone

Saddle Material/Comp:  Tusq Compensated

Bridge Material:  Ebony

End Graft:  Book Matched Sycamore

Tuning Machines:  Waverly 4063 Chrome

Neck Shape:  C Shape

Neck width at Nut: 1 ¾ “

Bridge String Spacing:  2 ¼ “

Neck Binding: Walnut w/ green & white Purfling

Body Binding:  Maple w/ same and brown herringbone purfling

Headstock Binding:  none; Walnut & Sycamore Veneers

Inlay Materials and Styling:  White MOP Logo & Dots

Bracing Material: Red Spruce

Top Bracing Width:  ¼ “

Scallop Height:  5/8 “

Back Bracing Pattern:  Live Radial Back

Finish Details:  6 Coats Lacquer, polish

Strings: D’Addario Custom Light

Monopole Mobility: 16.7

Final Frequencies: 106/186/226
