Guitar Data Sheet

Serial Number:       20-13

Date:  7/7/2014

Guitar Style   Dreadnaught D-14

Top Wood:  Sitka Spruce

Body Wood:  Figured Walnut

Nut Material:  Bone

Saddle Material/Comp:  Compensated Tusq

Bridge Material:  Ebony

End Graft:  Book Matched Sycamore

Tuning Machines:  Grover 305 Med Chrome

Neck Shape:  C Shape

Neck width at Nut: 1 ¾”

Bridge String Spacing:  2 ¼ “

Neck Binding: Walnut

Body Binding:  Maple w/ green stripe. Black herringbone on top.

Headstock Binding:  None. Walnut & Sycamore veneers

Inlay Materials and Styling:  Abalone Logo and Dots

Bracing Material: Red Spruce

Top Bracing Width:  ¼ “

Scallop Height:  5/8 “

Back Bracing Pattern:  Ladder Braced

Finish Details:  6 Coats Lacquer; Polish

Strings: D’Addario Light

Monopole Mobility: Not Tested

Final Frequencies: Not Tested
